Coultershaw beam pump

Overview

Heritage Category:
Scheduled Monument
List Entry Number:
1005817
Date first listed:
13-Apr-1981

Map

Ordnance survey map of Coultershaw beam pump
© Crown Copyright and database right 2019. All rights reserved. Ordnance Survey Licence number 100024900.
© British Crown and SeaZone Solutions Limited 2019. All rights reserved. Licence number 102006.006.
Use of this data is subject to Terms and Conditions.

The above map is for quick reference purposes only and may not be to scale. For a copy of the full scale map, please see the attached PDF - 1005817 .pdf

The PDF will be generated from our live systems and may take a few minutes to download depending on how busy our servers are. We apologise for this delay.

This copy shows the entry on 22-Oct-2019 at 16:58:35.

Location

The building or site itself may lie within the boundary of more than one authority.

County:
West Sussex
District:
Chichester (District Authority)
Parish:
Petworth
National Park:
SOUTH DOWNS
National Grid Reference:
SU 97208 19409

Summary

Coultershaw Beam Pump, 46m SSW of Coultershaw Farm House.

Reasons for Designation

Coultershaw Beam Pump, 46m SSW of Coultershaw Farm House, is a rare survival of a water-powered beam pump. It marked a significant 18th century innovation in the development of mechanised water supply. It is the only known survival of an almost exact copy of George Sorocold’s pumps erected under London Bridge in 1705. George Sorocold was an engineer from Lancashire who was hugely influential in pioneering work in water supply. He introduced pumps worked by water-wheels, which rose and fell in accordance with the level of the river or stream. As a surviving example of this design, albeit later in date, Coultershaw Beam Pump is of national importance.

History

See Details.

Details

This record was the subject of a minor enhancement on 30 October 2014. The record has been generated from an "old county number" (OCN) scheduling record. These are monuments that were not reviewed under the Monuments Protection Programme and are some of our oldest designation records. .

The monument includes a water wheel-powered triple beam pump built in 1782 to supply water to Petworth House. It is situated on the east side of the Rother, just south of Coultershaw Bridge near Petworth.

The water-wheel, which is 3.4m in diameter, was renewed in the 19th century and is cast iron framed. It was originally undershot but is now breast shot and drives a three-throw crankshaft which swings three beams pivoted at one end through connecting rods. The pump plunger rods are connected to the outer free ends of the beams. Water is pumped at a rate of over 90,000 litres per day along a 2.4 km cast iron pipeline to an underground cistern on Lawn Hill in Petworth Park.

The pump was originally sited in the basement of Coultershaw Watermill. However after the mill was destroyed by fire in the 1920’s, a weather-boarded barn with a tiled roof and brick footings was brought in to replace it. The beam pump was restored during the 1980s.

Legacy

The contents of this record have been generated from a legacy data system.

Legacy System number:
WS 484
Legacy System:
RSM - OCN

Sources

Websites
Sorocold, George (c.1668–1738?) , accessed 29-JUL-2009 from http://www.oxforddnb.com/view/article/47971. [Accessed 29-JUL-2009
Other
West Sussex HER 1617 - MWS2720. NMR SU91NE29. PastScape 249351

Legal

This monument is scheduled under the Ancient Monuments and Archaeological Areas Act 1979 as amended as it appears to the Secretary of State to be of national importance. This entry is a copy, the original is held by the Department for Digital, Culture, Media and Sport.
